The Hoke Monel Gyrolok Valve is engineered for demanding industrial environments requiring secure, leak-tight performance under high pressure and temperature conditions. Constructed from Monel, an alloy renowned for its exceptional resistance to seawater, acids, alkalis, and corrosive media, this valve ensures long-term reliability and safety.

Featuring 1/2″ Gyrolok inlet and outlet connections, this valve integrates seamlessly into precision tubing systems while delivering superior vibration resistance and sealing integrity. With an operational pressure rating of 2000 psig at 70°F (138 bar at 21°C) and a broad service temperature window from –20 to +350°F (–29 to +177°C), it is well-suited for offshore platforms, chemical processing, petrochemical systems, and industrial gas handling.

Its 0.375″ (9.50 mm) flow orifice supports high flow throughput while maintaining accurate process control.

Key Features

• Monel body for advanced corrosion protection

• 1/2″ Gyrolok inlet and outlet connections

• Rated 2000 psig at 70°F (138 bar at 21°C)

• Wide -20 to +350°F (-29 to +177°C) operating range

• 0.375″ (9.50 mm) orifice for increased flow capacity

• Leak-tight tube fitting design

• Excellent vibration resistance

• Suitable for aggressive media and harsh service environments

Technical Highlights

• Body Material: Monel

• Connection Type: Gyrolok compression fittings

• Valve Size: 1/2″

• Max Pressure: 2000 psig | 138 bar

• Operating Temperature Range:

  • –20 to +350°F

  • –29 to +177°C

• Orifice Diameter: 0.375 in (9.50 mm)

Applications

• Offshore oil & gas systems

• Corrosive chemical processing

• Petrochemical instrumentation

• Seawater service lines

• Specialty gas distribution

• High-pressure process control

• Industrial fluid handling

Benefits

• Exceptional corrosion resistance in aggressive environments

• Reliable sealing under high pressure

• Extended valve life with reduced maintenance

• High flow capacity with controlled performance

• Resistant to pitting and stress cracking
